With the Vitascan eVue Bladder Scanner, VITACON offers a portable and compact stand-alone solution for efficient patient care at various locations, especially for use in home care. Thanks to the integrated printer and practical carrying handle, the bladder scanner is ideally suited for flexible use. The robust construction ensures durability and minimizes the risk of infection, while the low operating costs increase cost savings.

Product at a Glance

• Portable stand-alone solution with integrated printer
• Parameters adjustable to individual requirements
• Operates with a gender-neutral algorithm
• Equipped with Wi-Fi functionality
• No routine calibration required
• Efficient patient care at various locations
• Specifically designed for use in home care

A special feature of the Vitascan eVue Bladder Scanner is the BladderVue™ bladder recognition technology. This eliminates interference factors and enables accurate measurements. Thanks to the gender-neutral algorithm, it is equally suitable for both women and men. Routine calibrations are not required.

The operation is via capacitive touch technology, which also works when wearing gloves. Parameters can be manually adjusted to individual requirements. Thanks to the optimal battery life, the Vitascan eVue Bladder Scanner offers uninterrupted operation. Software updates can easily be performed via USB. A comfortable carrying case is optionally available.

Specifications

• Vitascan eVue bladder scanner from VITACON
• Portable and compact stand-alone solution
• With integrated printer and carrying handle
• Capacitive touch technology operable even with gloves
• Touchscreen for quick operation with a single finger tap
• Manual adjustment of parameters to individual requirements
• Operates with a gender-neutral algorithm
• BladderVue™ bladder detection technology eliminates interfering factors
• Robust construction ensures long service life
• Equipped with Wi-Fi functionality
• Seamless connection to electronic health records (EHR)
• Fast and reliable data transfer
• No routine calibration required
• Simple software updates via USB
• Optimal battery life for uninterrupted operation
• Environmentally friendly, non-toxic battery without heavy metals
• Low operating costs and minimal risk of infection
• Efficient patient care at various locations
• Specifically designed for use in home care
• Comfortable carrying case optionally available

Indications

• Reduced urine output after surgical procedures
• Enlarged prostate
• Urethral stricture (narrowing of the urethra)
• Neurogenic bladder
• Spinal cord injury
• Stroke
• Impaired cognitive function
• Kidney stones or kidney tumors
• Urinary incontinence

Technical Specifications

• Volume range 0–1000 ml
• Accuracy +/- 7.5% at volumes greater than 100 ml
• +/- 7.5 ml at volumes less than 100 ml
• Probe frequency 3.45 MHz
• Scanning method Sector, 180 degrees
• Rotation positions 12 or 24
• Scan angle 130 degrees
• Display resolution 1280 x 800 pixels
• Display brightness 900–1000 cd/mA
• Drop test ISO 60601-1 standard, 15.3.4.1
• Input voltage 100–240 VAC, 50–60 Hz
• Dimensions (control unit) 26.3 x 22.7 x 12.5 cm
• Weight (control unit) 1.77 kg
• Dimensions (probe) 18.5 x 4.5 x 4.5 cm
• Weight (probe) 380 g

Scope of Delivery

• Vitascan eVue control unit with printer
• Vitascan v.2 probe
• USB-C cable
• User manual
