For monopolar and bipolar use.

The SU 140 D-MPC is the most complete model of the series. Like the 140 MPC, this coagulator has two separate controllers and can be operated with a manual switch. But also an eye-catching feature that is not common in small surgical units: a double foot switch for the activation of cutting and coagulation. This makes the SU 140 D-MPC the ideal solution for small procedures.

The Alsatom MPC system is a new generation of electrosurgical devices, equipped with the latest digital technology . These devices are equipped with five currents, each with an electronically controlled start impulse for optimal results and minimum output power. The currents are:

CUT: without modulation for clean cut without hemostasis.

BLEND: modulated combination of currents for cutting and hemostasis for coagulation of cuts.

COAG: a high-voltage "fulguration" for coagulation without contact and with a strong superficial effect. It is indispensable for many surgical needs.

MICRO: a low tension "pin-point, soft", extremely precise with an excellent depth effect (e.g. for hair removal in dermatology).

BIPOLAR: without modulation and extremely precise "micro" coagulation.

Technical specifications:

  • certified in accordance with standards IEC601-1 and IEC60601 CE 0051
  • operating frequency : 475 kHz
  • mains: 220V 260VA
  • control by microprocessor with auto-diagnostic function, automatic dynamic
  • dimensions: L23 x P24 x H10 cm
  • < li>weight: 4,750 kg
  • control by a double pedal: cutting/coagulation
  • possibility of a manual control stick
  • 5 operating modes: (W) - (ohm ) - (V) - CF:
    CUT: 140W - 500 ohm - 1200V - CF1.7
    BLEND 120W - 500 ohm - 1450V - CF2.8
    COAG 120W - 500 ohm - 2770V - CF6.9
    COAG micro 60W - 200 ohm - 1420V - CF2.8
    BIP COAG 100W - 100 ohm - 400V - CF1.4.

With standard accessories:

  • dual control pedal (COAG-CUT)
  • sterilizable electrode handle with 2 meter cord
  • knife electrode (Ref E1)
  • needle electrode (large (Ref E5)
  • needle electrode (fine) (Ref E7)
  • button electrode diameter 2.5 mm (Ref E12)
  • li>
  • button electrode diameter 4.0 mm (Ref E14)
  • Loop electrode, diameter 5mm (E 21)
  • rubber mounting strap for neutral electrode plate with button (Ref EIP/9)
  • neutral electrode mounting strap (Ref 1FFE ).

Optional:
NP/GP electrode made of flexible conductive rubber (part of configuration B700/B)

Alsatom 140D - MPC coagulator

Mono- en bipolaire electro coagulator. Met dubbele voetschakelaar.

Optioneel

€2.165,83 excl. VAT Regular price €2.599,00 incl. VAT
Regular price €2.165,83 excl. VAT Sale price €2.599,00 incl. VAT

Art. no.

1303003

Availability

Will be ordered for you

Added to cart!

Bezorging en service

Free shipping from €100 excl. VAT and €121 incl. VAT (NL)

On weekdays before 3 PM and in stock, shipped same day

For both professionals and consumers

For Praktijk Plus customers, discounts up to 25%*

Your practice in NL can order on account

For monopolar and bipolar use.

The SU 140 D-MPC is the most complete model of the series. Like the 140 MPC, this coagulator has two separate controllers and can be operated with a manual switch. But also an eye-catching feature that is not common in small surgical units: a double foot switch for the activation of cutting and coagulation. This makes the SU 140 D-MPC the ideal solution for small procedures.

The Alsatom MPC system is a new generation of electrosurgical devices, equipped with the latest digital technology . These devices are equipped with five currents, each with an electronically controlled start impulse for optimal results and minimum output power. The currents are:

CUT: without modulation for clean cut without hemostasis.

BLEND: modulated combination of currents for cutting and hemostasis for coagulation of cuts.

COAG: a high-voltage "fulguration" for coagulation without contact and with a strong superficial effect. It is indispensable for many surgical needs.

MICRO: a low tension "pin-point, soft", extremely precise with an excellent depth effect (e.g. for hair removal in dermatology).

BIPOLAR: without modulation and extremely precise "micro" coagulation.

Technical specifications:

  • certified in accordance with standards IEC601-1 and IEC60601 CE 0051
  • operating frequency : 475 kHz
  • mains: 220V 260VA
  • control by microprocessor with auto-diagnostic function, automatic dynamic
  • dimensions: L23 x P24 x H10 cm
  • < li>weight: 4,750 kg
  • control by a double pedal: cutting/coagulation
  • possibility of a manual control stick
  • 5 operating modes: (W) - (ohm ) - (V) - CF:
    CUT: 140W - 500 ohm - 1200V - CF1.7
    BLEND 120W - 500 ohm - 1450V - CF2.8
    COAG 120W - 500 ohm - 2770V - CF6.9
    COAG micro 60W - 200 ohm - 1420V - CF2.8
    BIP COAG 100W - 100 ohm - 400V - CF1.4.

With standard accessories:

  • dual control pedal (COAG-CUT)
  • sterilizable electrode handle with 2 meter cord
  • knife electrode (Ref E1)
  • needle electrode (large (Ref E5)
  • needle electrode (fine) (Ref E7)
  • button electrode diameter 2.5 mm (Ref E12)
  • li>
  • button electrode diameter 4.0 mm (Ref E14)
  • Loop electrode, diameter 5mm (E 21)
  • rubber mounting strap for neutral electrode plate with button (Ref EIP/9)
  • neutral electrode mounting strap (Ref 1FFE ).

Optional:
NP/GP electrode made of flexible conductive rubber (part of configuration B700/B)
